Acting type compensation

Mode/Function Description 2/2 NC - Ratio

Pneumatic connection type cartridge, base F type

Medium contact material operator: stainless steel

Orifice: brass, stainless steel

Base: PEEK

Seal: FPM

Mounting direction apathy

Media air, oxygen, neutral gas

Pressure range @ Port 1 0 to 7 barrels.

Back pressure @ Port 2(※) ≤ 10% of inlet pressure

Traffic @ 2.4 bar relative. @20 °C ≥ 190 L/min

Internal leakage @ 20°C (ml/min) < 1@0 ~7 bar relative.

External leakage at 20°C (ml/min) < 1@7 bar relative.

Storage temperature -- 20 ~ +70°C

The ambient temperature ranges from 5 °C to +50°C

Media operating temperature 5~+50°C

Protection (DIN 40050) IP51 protection grade

Duty cycle 100% ED degree

Front-end Filter recommended 20pcs (not included)

Weight 40±5 grams

E_MVPH.pdf
