The width of the body is 8 mm

Port number 2, port number 3

Job No. 2

Medium dry air, inert gas

Working pressure range 0~1.2 mpa, 0~0.8 mpa

Flow rate (Newton/min) 25 ±10%, 28 ±10%

Response time On: 0.7~2.0 ±1 ms Off: 0.5~1.0 ±1 ms

Working fluid temperature -- 10~+50℃

The ambient temperature ranges from -10 ℃ to +50℃

Storage temperature -- 10~+50℃

Voltage acceleration: DC 24V, hold: DC 5V, DC 12V

Power consumption: 0.8w, 0.5W (hold), 1.2W, 1.44W

Filter element 40 microns

No need for lubrication

The maximum operating frequency is 500 Hz (250Hz with a driver board), 200Hz, and 280Hz

IP protection Level IP52 Protection level

Weight 8g
