Hole number 6 Ann

Pipe diameter 1/8

Port number 3

Position number 2

Medium air, low vacuum

Working pressure range -101 kPa ~ 0.7 MPa

Withstand pressure 1 MPa (low vacuum: -101 kPa)

Effective hole P→A: 5.2 mm 2, R→A: 6.0 mm 2

A→P: 6.2 mm 2, A→R: 5.8 mm 2

Response time is 20 milliseconds

Ambient temperature -- 5~+50°C (no icing)

Voltage DC 24V

Energy consumption is 7W

Available voltage range ±10%

Insulation class F

Weight 164g (including support: 181)
