The fuselage width is 18 mm

Hole number. 8 a

Port size 1/4

Port number 5

Job numbers 2, 3

Medium air

Working pressure range 0.15~0.7 mpa, 0.2~0.7 mpa (5/3)

Withstand voltage 1 mpa

Flow 599~1470 L/min

Effective orifice Valve Body port: 15 mm2, 16.3/27/12.4 mm2 (5/3) Manifold: 15 mm2, 13.5/18.4/11 mm2 (5/3)

Response time 23ms, 50ms (5/3)

Maximum operating frequency 5 Hz

Ambient temperature +5 °C to +50°C

Voltage AC 110V, AC 220V (50/60) Hz, DC 6/12/24V

Power consumption AC = 1.6/2.5VA, DC6/12V = 1.2W, DC24V = 0.55W (indicator)

Available voltage range ±10%

Insulation class B

Weight: 77g, 102g, 106g
