The width of the body is 15 mm

Hole number. 6 a

The port size is 1/8

Port number 5

Job numbers 2, 3

Medium air

Working pressure range 0.15~0.7 mpa, 0.2~0.7 mpa (5/3)

Withstand voltage 1 mpa

Flow rate: 381~762 L/min

Effective orifice

Body port: 11 mm /14.6/9.5 mm (C/P/R), 2,9.5, 2

Manifold: 10 mm, 7.5/13/8 mm (C/P/R) 2 2

Response time is 30 milliseconds

Ambient temperature -5~+50°C (no icing)

Voltage AC 110V, 220V (50/60) Hz, DC12/24V

Power consumption AC =2.5 volt-ampere, DC =0.95 watts

Available voltage range ±10%

Insulation class F

Weight 83g, 118g, 127g

E_MVSP-156.pdf
