Hole number 6A, 8A
Piping caliber G1/8, G1/4
Port number 5
Position number 2
Moderate air
Working pressure range 0.2~0.8 mpa
Withstand voltage 1 mpa
Flow 980 L/min
Effective orifice 18mm 2_
The response time is 38 milliseconds
Ambient temperature -5~+50°C (no icing)
Voltage AC 110V, AC 220V (50/60) Hz, AC DC 24V
Energy consumption AC =4.8/4.4 volts, 6/4.9 voltamere; Dc is equal to 2W
Available voltage range ±10%
Insulation class F
Weight: 233g, 343g
E_MVSN-220.pdf
