Hole number 8 Ann
Piping caliber 1/4
Port number 5
Position number 2,3
Moderate air
Working pressure range 0.2~1.2 mpa, 0.3~1.2 mpa (5/3)
Withstand pressure 1.5 mpa
Effective orifice 18mm 2, 16mm 2 (5/3)
Response time 40ms, 35ms (5/3)
Ambient temperature -5~+50°C (no icing)
Voltage AC 110V, AC 220V (50/60) Hz, DC 24V
Energy consumption AC =6/4.9 volt-ampere, DC =2 watts
Available voltage range ±10%
Insulation class F
Weight: 255g, 350g, 405g
