Hole number 15"

Pipe diameter 1/2

Port number 3, 5

Position number 2, position number 3

Moderate air

Working pressure range 0.2~0.8 mpa, 0.3~0.8 mpa

Working pressure (LP) 0~0.8 mpa

Pilot pressure range (LP) (0.34× point *

Withstand voltage 1 mpa

Effective orifice 60 mm 2, 50 mm 2, 30 mm 2

Response time is 50 milliseconds

Ambient temperature -5~+50°C (no icing)

Voltage AC 110V, 220V, 24V (50/60) Hz, DC24V, 12V

Energy consumption AC =4.8/4.4 volt-ampere, 6/4.9 volt-ampere, 6.7/5.4 volt-ampere, DC =2 watts, 2.5 watts

Available voltage range ±10%

Insulation class F

Weight 325g, 455g, 339g, 464g, 525g
