Hole number: 6A, 8A

Port size 1/8, 1/4

Port number 3, 5

Job numbers 2, 3

Medium air

Working pressure range 0.2~0.8 mpa, 0.3~0.8 mpa

Working pressure (LP) 0~0.8 mpa

Pilot pressure range (LP) (0.34×P * +0.1) ~ 0.5MPa

Withstand voltage 1 mpa

Effective orifice 16 mm2, 18 mm2

The response time is 30 milliseconds, 40 milliseconds

Ambient temperature -5~+50°C (no icing)

Voltage AC 110V, 220V, 24V (50/60) Hz, DC24V, 12V

Power consumption AC =4.8/4.4 volt-ampere, 6/4.9 volt-ampere, 6.7/5.4 volt-ampere, DC =2 W, 2.5 W

Available voltage range ±10%

Insulation class F

Weight 181g, 294g, 198g, 313g, 352g
