The width of the body is 10 mm

Hole number. M5

Port size M5x0.8

Port number 5

Job No. 2

Medium air

Working pressure range 0.2~0.7 mpa

Operating performance (LP) 0.0 to 0.7 mpa

Pilot pressure range (LP) 0.25~0.7 mpa

Withstand voltage 1 mpa

Flow 218 L/min

Effective orifice 4.5mm square mm

Response time is 15 milliseconds

Maximum operating frequency 5 Hz

Ambient temperature +5 °C to +50°C

Voltage AC 110 (50/60) Hz, DC 6/12/24 V

Power consumption AC = 1.6/2.5VA, DC =0.55W (indicator)

Available voltage range ±10%

Insulation class B

Weight 30g, 44g, 59g
