Hole number: 10 Ann

Port size 3/8

Port number 3, 5

Job numbers 2, 3

Medium air

Working pressure range 0.2~0.8 mpa, 0.3~0.8 mpa

Working pressure (LP) 0.08 mpa

Pilot pressure range (LP) (0.34×P * +0.1) ~ 0.5MPa

Withstand voltage 1 mpa

Effective orifice 30mm 2, 35 mm2, 25 mm2

Response time is 50 milliseconds

Ambient temperature -5~+50°C (no icing)

Voltage AC 110V, 220V, 24V (50/60) Hz, DC24V, 12V

Power consumption AC =4.8/4.4 volt-ampere, 6/4.9 volt-ampere, 6.7/5.4 volt-ampere, DC =2 W, 2.5 W

Available voltage range ±10%

Insulation class F

Weight 325g, 453g, 320g, 444g, 505g
